MIX-MATIC C/F
TILTING COOK / CHILL PAN WITH MIXING SYSTEMTHE COOK&CHILL YOU CAN TRUST
Mix-Matic C/F is a new-concept tilting pan with mixing system ideal for cooking and then rapidly chill stocks, soups, purées, sauces, custards, etc. It is intended for use in centralised kitchens, delicatessens and industrial food processing plants.
Fully automatic, it reduces manual procedures to a minimum and allows completely safe cooking and chilling in a single appliance, with no need to transfer the product from the boiling pan to the chiller. Built in two models with a capacity of 150 and 300 litres, Mix-Matic 150 and 300 C/F are heated indirectly, by electric heating elements or steam (1 bar: 120 ºC. 1,5 bar: 127 ºC), in the jacket. Chilling is obtained by circulating refrigerated water through the jacket.
The mixing system continuously mixes and amalgamates the product during cooking and chilling, keeping it smoother and preventing the product from sticking to the pan. The mixing system is easily dismantled for cleaning after use.
The appliance is controlled by the control panel installed on a mobile arm: it is electromechanical as standard, or electronic with a PLC upon request. The PLC version can be connected to the Nilma CCMP interactive software, enabling the recipe management and storing, the product traceability, the logging of HACCP parameters and the appliance diagnostics. Everything under control, even via smartphone.
